| Product introduction: Equipment number: 20171108 |
| Model: WDL-CXLSD300 |
| Working temperature range: RT (room temperature) ~ 100℃ adjustable |
| Temperature uniformity: ±2.5℃％ (tested at constant temperature without load) |
| Heating speed: RT~60℃ less than 20 minutes |
| Air transport mode: Double duct horizontal circulation air transport, good temperature uniformity. |
| Internal effective dimensions: 2000*950*300 (depth*width*height mm) |
| Chain plate effective length: 3000*900 (length*width mm) |
| Internal material: stainless steel |
| Internal structure: Speed regulating stainless steel chain plate |
| Power supply: 380V/50HZ (3 phases + neutral wire + ground wire) |
| Input power: 12KW |
| Protection device: over-temperature protection, leakage protection, grounding protection |
| After-sales service commitment: one-year warranty and maintenance for the whole machine. |
| The above products can be customized in various non-standard sizes according to customer needs! |
| Product Introduction: Equipment No.: 2013-1-12 |
| Model: CXLSD-7001 |
| Working temperature range: RT (room temperature) ~ 180℃ adjustable |
| Temperature uniformity: ±2.5℃％ (tested at constant temperature without load) |
| Heating speed: RT~100℃ less than 20 minutes |
| Air transport mode: Double duct horizontal circulation air transport, good temperature uniformity. |
| Internal effective dimensions: 6000*800*350 (depth*width*height mm) |
| Chain plate effective length: 7000*800 (length*width mm) |
| Internal material: stainless steel |
| Internal structure: Speed regulating stainless steel chain plate |
| Power supply: 380V/50HZ (3 phases + neutral wire + ground wire) |
| Input power: 27KW |
| Protection device: over-temperature protection, leakage protection, grounding protection |
| After-sales service commitment: one-year warranty and maintenance for the whole machine. |
| The above products can be customized in various non-standard sizes according to customer needs! |
